Grove GMK5150XL

The new GMK5150L-1 delivers great return on investment due to outstanding lifting capacities and greater jobsite accessibility.

SPECIFICATIONS

Capacity:

150t
Boom Length:

68.7m
Fly Length:

9.9 - 16.2m
Tip Height:
Number of Winches:

2
Counterweight:

DOWNLOADS

FEATURES

The new GMK5150XL delivers great return on investment due to outstanding lifting capacities and greater jobsite accessibility.

Get impressive strength and reach including 8,1 t lifting capacity with 68,7 m main boom. The boom can be further extended with a 16,2 m swingaway jib and one 8 m boom extension and/or one 6 m jib insert to a maximum length of 30,2 m with up to 40° offset.

Counterweight configurations enable setup from 1 t counterweight to taxi configurations of 12 t to 16,5 t per axle. This results in greater roadability and transport savings. The single engine concept on the GMK5150XL with the latest EUROMOT 5/Tier 4 final engine reduces fuel consumption to a minimum.

Using the ECO mode, the GMK5150XL is the most fuel efficient crane in its class. Approved for HVO – up to 90 % CO2 reduction. The GMK5150XL redefines the 150 t 5-axle class once more. Whilst offering best in class taxi and maxi charts it also comes with the longest boom of any crane below 220 t capacity. Compact length and 2,75 m width allow access to even narrow jobsites, while optimizing crane set up and lifting position.A single Tier 4 Final engine powers the crane. The engine drives both the carrier and superstructure, reducing overall weight and lowering fuel consumption, which leads to lower operating and maintenance costs.
